GN 736.1 Knurled control handwheels

with revolving handle, aluminium

Select type




Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Material

Knurled aluminium profile, anodised, black colour.

Cap

Acetal resin based (POM) technopolymer, light-grey colour.

Handle

Polyamide based (PA) technopolymer, black colour, glossy finish.

Standard executions

  • GN 736.1-B-A: H8 reamed hole, without handle.
  • GN 736.1-B-D: H8 reamed hole, with revolving handle.
  • GN 736.1-K-A: H8 reamed hole and keyway in compliance with DIN 6885/1 tolerance P9, without handle.
  • GN 736.1-K-D:H8 reamed hole and keyway in compliance with DIN 6885/1 tolerance P9, with revolving handle.
General information

Special executions on request

  • On the surface of the cap words, marks, graphic symbols, etc...can be tampoprinted in colours.
  • On the plain surface of the handwheel precision graduations can be laser-engraved (see Graduations).
