GN 815.1 Ball spring plungers

Hexagon socket head, steel or stainless steel

Select type




Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Standard executions

Black-oxide steel body, hardened steel ball

  • GN 815.1-ST: stainless steel normal end-force spring.
  • GN 815.1-STS: steel spring with heavy end-force.

AISI 303 stainless steel body, hardened AISI 420C stainless steel ball :

  • GN 815.1-NI: stainless steel normal end-force spring.
  • GN 815.1-NIS: Stainless steel heavy end-force spring.
General information

Features and applications

GN 815.1 plungers are used as stops or push elements.

The collar provides an indication of the mounting position.
