GN 6319.1 Levelling washers

single body, steel



Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Material

Case-hardened steel (hardening depth 0.2 - 0.4 mm), hardness (550 + 100) HV 10.

General information

Features and applications

GN 6319.1 levelling washers are suitable for locking mechanical parts on non-parallel surfaces.

The coupling of the two spherical surfaces of the washers allows a very high load resistance.

Other executions

Special executions on request

GN 6319.1-NI: AISI 303 stainless steel levelling washers.
