GN 608.1 Indexing plungers with flange
rest in retracted position, zinc alloy
Main specifications
Base flange
Zinc-plated die-cast zinc alloy with two holes for assembly with countersunk head screws.
Plunger
Black-oxide steel with hardened end.
Suggested tolerance for matching hole = H7.
Knob
High-resilience polyamide based (PA) technopolymer, black colour, matte finish.
General information
Features and applications
GN 608.1 indexing plungers with rest position have compact dimensions and are used on thin sheets and where the plunger needs to be locked in the retracted position.
Models all rights reserved in accordance with the law. Always mention the source when reproducing our drawings and photos.
