GN 505.4 T-Nuts

quick-insert, steel




Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Standard executions

Zinc-plated steel.

General information

Features and applications

GN 505.4 dowels for T-slots are suitable for use on aluminium sections for quick insert.

Inserting the dowel upright into the T-slot and rotating it clockwise by 90°, the toothing will insert into the profile to secure fitting. To remove the dowel from the slot, rotate it anticlockwise by 90°.
