PA01 - PA02 - PA05 Position indicators

positive drive, steel



Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Case

Zinc-plated steel.

Bezel

AISI 303 stainless steel.

Window

Glass.

Dial

Natural matte anodised aluminium.

Clockwise or anti-clockwise graduation, black colour.

Reading

The black pointer indicates the number of turns of the spindle from the start position (0); the red pointer indicates the fractions of turn.

Ratio

To choose the ratio see "Positive drive position indicators".

General information

Features and applications

Digital-analogue positive drive indicators are suitable with spindles in any position.

To choose the handwheel see the table "handwheels/knobs-possible assembly with indicators".

Other executions

Special executions on request

  • Special dial with logo or customised graduations
  • Special ratios
  • Single pointer
  • Window in plexiglass instead of glass.
Elesa
Models all rights reserved in accordance with the law. Always mention the source when reproducing our drawings and photos.
