CMT.AE-V0 Lever latches

with fold-away knob, technopolymer




Select item

loading

Technical specifications

Scroll horizontally
Main specifications

Material

Rotor, stator, fold-away knob, closing lever and nut (M22x1.5) in glass-fibre reinforced polyamide based (PA) technopolymer certified self-extinguish UL-94 V0, black colour, matte finish.

Packing ring

SBR rubber.

Internal toothed washer

AISI 304 stainless steel

Self-tapping screw

AISI 304 stainless steel

Rotation

90°.

IP protection

IP 65 protection class, according to EN 60529

General information

Technical data

The "V0" certification in accordance with UL-94 V (Underwriters Laboratories) (see Technical data) indicates that on a plastic test sample with specific shape and dimensions, in the vertical position, the flame is extinguished within 10 seconds, without generating incandescent drops.

CMT.AE-V0 - Compression lever latches
Other executions

Special executions on request

Closing lever with l2 ledge in other dimensions.
