GN 321 (inch sizes) Solid handwheels

Aluminium

Select type

GN 321-A (inch sizes)

GN 321-A (inch sizes)

Solid handwheels

GN 321-R (inch sizes)

GN 321-R (inch sizes)

Solid handwheels

Revolving handle

Select item

Technical specifications

Scroll horizontally

Main specifications
Other executions
General information

Main specifications

Material

Cast aluminium, fine sandblasted matte surface, turned and mirror-polished rim.

Standard executions

Standard reamed hole.

GN 321-A: without handle.

GN 321-R: with revolving handle in polyamide based (PA) technopolymer, black colour, matte finish.

Other executions

Special executions on request

Handwheels with safety bushing GN 000.5.

GN 323 handwheels with black epoxy resin coating, matte finish.

Handwheels with keyway in compliance with ANSI B17.1-1967 tolerance.

General information

Technical Data

Axial and radial runout lower than IT 12.
