HGFT-PR (inch sizes) Oil level sight glasses

with prismatic window, technopolymer

Select item

Technical specifications

Scroll horizontally

Main specifications
General information

Main specifications

Material

Polyamide based (PA) technopolymer, black colour, glossy finish.

Prismatic window

Transparent polyamide based (PA-T/AR) technopolymer. The window consists of a continuous series of prisms which provide a clear and immediate reading of the level of the oil contained in the reservoir.

Packing ring

NBR synthetic rubber.

Maximum continuous working temperature

212°F (100°C) at 3 bar pressure.

General information

Note

For use with fluids containing special additives, please contact ELESA Sales Department.

Accessories on request

Brass nut type GH.- for fitting to reservoirs with wall thickness smaller than 0.20 (5 mm).
